    Ebike Controller Parts - Twist Throttle, Brake Sensor, KT LCD Display LCD3 LCD5 ,E bike Motor Extension Cable Brake Lever, PAS Sensor

    $38.08 $12.08
    Unit price  per
    FREE EXPRESS SHIPPING

    FREE EXPRESS SHIPPING

    30 DAY SATISFACTION GUARANTEE

    100% SECURE PAYMENT

    SPECIFICATIONS

    Item 1: Ebike Thumb throttle

    Item 2: Ebike PAS

    Item 3: Ebike LCD Display

    Item 4: Ebike Brake Sensor

    Item 5: Ebike Controller Accessories

    Type: DISPLAY

    Suitable for voltage: 24V 36V 48V KT Controller

    Compatible Model: Ebike KT Controller

    Brand Name: WEXPLORE

    Note:

    This product contains 11 options, all options only support Kunteng controller, 24V 36V 48V 250W 350W 500W 750W 1000W 1500W KT controller.

    12 Magnets PAS Sensor

    Type : PAS Sensor

    Installation : Left

    Voltage : Use with 24V / 36V / 48V contoller

    Magnet : 12 Magnets

    Cable Length : 90cm not include the sensor and connector

    Connector : 3Pin SM Connector

    Corresponding time when brake:<0.001S

    Corresponding distance:2-3mm

    Hall Electric Life:>20M times

    Attention before order:

    For LCD display, if your original PAS is 8 magnents,please set the parameter C1=07.

    For LED display, you need to choose the same magnets as before.

    Adaptable controller:Kunteng/Lishui/Jiannuo controller

    Important notice of KT display:

    KT LCD3 LCD4 LCD5 EBike LCD Display are for Kunteng Series Controllers. It only fits KT series controllers. It is not suitable for other controllers.

    1. Note: How to determine the value of the parameter P5 ? The formula is LVC+P5/3.77.

    For 24V battery, LVC=20V, P5/3.77=1.

    For 36V battery, LVC=30V, P5/3.77=1.5.

    For 48V battery, LVC=40V, P5/3.77=2.

    You can adjust P5 parameter by your own battery discharge curve.

    Specifications:

    1. Data display:it shows the riding speed, a single mileage and cumulative mileage, riding time, power-assist gear, motor power and temperature, battery voltage and charge status, brake status and the used ambient temperature and other cycling parameters;

    2. Intelligent power:a true reflection of the battery charge, real-time recording of the power consumption to ensure riding mileage;

    3. Stalls setting:multi-gear switch and automatic save of the power-assist gear, and it can restore power-off stall state when turned on;

    4. Parameter setting:with a number of user parameter setting functions, motor parameters, velocity measurement parameters, speed-limit parameters, power parameters, power-assist control parameters, the minimum controller voltage and maximum current parameters and other operating models for settings adjustment ;

    5. Data view:Users can view historical driving data and clear accordingly, view single or cumulative riding time, riding mileage, maximum speed and average speed of single riding;

    6. Vehicle boosting:With 6Km/h power-assisting functions, the boost logo flashes during boosting, and riders can use it when driving the vehicle and the vehicle driving is labor-saving and easy;

    7. Cruise and constant speed:With the setting and display of the cruise, achieving to automatically maintain the vehicle speed, so that the vehicle drives at a constant speed;

    8. Night driving:With the functions of LCD backlit display and headlight switch control, instrument backlighting and headlights can be turned on during driving at night;

    9. Password setting:With three-bit of power-on password setting;

    10. Automatically prompt:For the appeared failure of the vehicle, it can prompt different fault codes for easy inspection and maintenance of vehicle. With a temperature display for motor operation and it is to achieve the ultra-temperature alarm and motor protection;

    11. Use five-line of digital communication, the instrument has good compatibility and interchangeability, different instruments can be conducted the data exchanges and parameters copy directly;

    12. Host part and operation buttons of the meter use sub-structure design, making the operation to be more reasonable and convenient;

    13. Supply voltage of 24V, 36V, 48V can be automatically identified and compatible;

    14. Black housing

    About Ebike Display LCD5

    1. Dimension: 16.5x51x77mm.
    2.Supply voltage of 24V, 36V, 48V can be automatically identified and compatible;
    3.SM Cable Length: 160cm

    About Ebike Display LCD4

    1.Dimension: 19x54x10mm.
    2.Supply voltage of 24V, 36V, 48V can be automatically identified and compatible;
    3.SM Cable Length: 160cm

    About Ebike Display LCD3

    1.Cable Length: 180cm
    2.This electric bike display connector is not waterproof.
    3.Work voltage:DC 24V 36V 48V

    Julet 9Pin Wheel Motor Extension Cabl

    * This is motor extend cable with Female and Male 9pin connectors.
    This cable is a convert cable.Make your motor (waterproof connector) convert to the SM connector.And it can extend the length.

    * Waterproof cable Length: 60cm
    SM cable Length:60cm

    * Color: Black(as pictures show)

    * Please check pictures for connector compatibility before your purchasing.

    * Voltage :12-72V

    * Plug:9 pin

    * Usage:Ebike,Electric Bicycle

    Ebike brake sensor:

    1.Connector:Male SM 2 Pin

    2.Cable length:165cm

    3.Application type:Hydraulic or Mechanical Brake

    4.Compatible with KT controller and other brands.

    Ebike Thumb Throttle

    Type:130X Thumb Throttle

    Voltage:24V 36V 48V

    Wire length:160cm(SM)

    Plug:3 Pin SM Connector

    Installation:Left/Right

    Weight:100G

    Ebike Twist Throttle

    Type:Twist Throttle

    Voltage:24V 36V 48V

    Wire length:150cm(SM)

    Plug:3 Pin SM Connector

    Installation: Left / Right

    Weight:195G

    Ebike Brake Lever

    Type:Ebike Brake Lever

    Voltage:24V 36V 48V

    Wire length:150cm(SM)

    Plug: 2 Pin SM Connector

    Installation: Left and Right

    Weight:270G

    Material: aluminum alloy

    KT-LCD3 / LCD8 Display Bracket

    Material: ABS
    Adaptation: KT-LCD3 / LCD8 Display
